Guangzhou Ming Rui electronic end of the high-frequency transformer orders jumped at 2014-10-26 I think the Procurement Division 5 HY-B02 automatic taping machine with a flat-HY-B08 automatic core assembly machine, the more business that Deng Hui R briefly explain Guangzhou Ming Rui electronics companies.
Panyu District, Guangzhou City, Village Ming Rui Electronic Factory Main high-frequency transformers, filters, magnetic, magnetic, inductors. Companies adhering to the "customer first, forge ahead" business philosophy, the "customers first" principle to provide our clients with quality services.
HY-B02 automatic taping machine Features:
SCM control, stepper motor operation, high quality, high efficiency, low noise.
For a variety of high and low frequency transformers, inductors, relays, etc. with insulating tape tape core packs
1, the use of single-chip control, stepper motor operation, high-quality, low-cost, simple operation, durable;
2, high efficiency, saving taping time, the core of about 20,000 per day, approximately 30,000 line package;
3, cut with a neat, good appearance;
4, large iron-type tape packs can be set
HY-B02 automatic core package melter - Product parameters:
Applicable products: electronic transformers, inductors, relays
Taping Speed: inductor core: 25 ~ 40pcs / min
Insulation Tape: 50 ~ 60 pcs / min
Power supply: ac220v ± 10, v 50/60 hz
Net weight: 30 kg
HY-B08 automatic core assembly machine Product Description:
1, the core product in the HY-B07 automatic assembly packet basis on the increase melter chassis frame, you can simultaneously increase the local stacking tool, making HY-B08 automatic core assembly function more atmospheric and practical, but also efficiency increased, the fastest per minute can be raised to 68 cores.
2, the yield is about 52-68 pcs / min;
3, using the man-machine interface control, convenient and simple to operate, there is change tape alerts.
A functional and workflow:
1. Function: auto-complete transformer core, skeleton assembled and plastic packages.
2. Workflow: material on the core material on the skeleton → → → assembled at the core material encapsulated → Cutting →
Second, the equipment technical parameters:
Control: programmable logic controller (PLC) and the 7.1-inch touch screen parameter setting and command input
Working mode: Auto / Manual / single station cycle
Feed: automatic feed
Production speed: 52-68pcs / min
Power supply voltage: AC220V 50-60HZ
Air pressure: 0.4-0.6Mpa
Machine Dimensions: Height 1900mm, width 900mm, length 1500mm
