Using core automatic assembling taping machine package tape matters needing attention
When the transformer manufacturers procurement core automatic assembling taping machine back to the production of transformer, transformer, what are the requirements on the tape? To pay attention to what? Below by Hui more Xiaobian with everybody is talking about.
1, core assembly, can not have obvious dislocation:
2, different material core can not be assembled in the same products, plus material pad GAP material shall be the temperature of 130 DEG C, core composite surface must be absolutely clean, otherwise the impregnation can cause "L" value decreased;
3, the assembly before confirming the core has no obvious damage, deformation;
4, such as SPEC request, according to the requirements of operations, if no requirements will be GAP core is assembled on the early group of winding side (horizontal BOBBIN), the PIN side (vertical BOBBIN);
5, core layer with 2-3 adhesive tape winding tape fixed, flat, dense, adhesive tape starting at PIN side (vertical), a primary side (horizontal), ended at PIN side (vertical), a primary side (horizontal) corner, belt width to physical appearance or less than the core width of 0.3-0.5mm is preferred;
Automatic assembly machine core encapsulated physical map:
