Introduction of superior performance configuration of Dongguan tunnel furnace drying line
Our Dongguan Hui more scientific and technical professional production of infrared tunnel furnace drying line, the division of domestic and international high precision machining equipment and improve the production process, establish a quality of survival, quality and development, quality and efficiency of the enterprise property. Today, we will introduce the superior performance of the Dongguan tunnel oven drying line.
1, exterior size: L6000W900H1250mm. (size can be customized)
2, baking area size: L4800mm*W700mm*H150mm. Material placed in front of the 600mm, 600mm, discharge area and out
Material area with stainless steel plate. The inlet outlet is highly regulated, and the adjustment range is 30-100MM.
3, import and export of SUS201=1.5MM protection board.
Number 4: 2, the body is divided into 3 sections. Section a baking zone, 250MM low temperature zone, 2 temperature zone.
5, the furnace body adopts 1.5MM/1.2MM galvanized plate bending welding outside the upper part of the oblique angle.
6, the furnace body wall for SUS201 1.2MM stainless steel, each of the infrared lamp tube with stainless steel reflector.
7, power: 1/2P Taiwan East yuan inverter and 1/2P motor.
8, transmission speed 0.2~3M/min (frequency conversion adjustment)
9, conveying carrier: transmission bandwidth 700MM 30*15 stainless steel flat, spacing 46MM. On both sides of 6 double pitch high carbon chain.
Dongguan Hui Yue technology tunnel furnace drying line in kind:
